Description
| Cat 5e UTP, Cat 6e UTP | |||||||||
| Cabluri pentru retele de calculatoare | Computer network cables | |||||||||
| Constructie | Construction | ||||||||
| 1.Conductor de cupru unifilar | 1.Solid copper conductor | ||||||||
| 2.Izolatie din PE | 2.PE insulation | ||||||||
| 3.Ecran din folie AluPet+fir continuitate sau din tresa din sirme de cupru | 3. Screen of AluPet foil + drain wire or copper braided wire | ||||||||
| 4.Manta exterioara din PVC | 4.PVC outer sheath | ||||||||
| Specificatia tehnica | Technical specification | ||||||||
| Raza de curbura: min. 8x Cable diameter | Bending radius : 8x Cable diameter | ||||||||
| Tensiunea de lucru : 250 V | Working voltage : 250 V | ||||||||
| Tensiunea de testare : 1.2 KV | Test voltage : 1.2 KV | ||||||||
| Gama de temperatura : -20 / +60ºC | Temp. range : -20 / +60ºC | ||||||||
| Rezistenta de izolatie: min. 5000 MΩkm | Insulation resistance: min. 5000 MΩkm | ||||||||
| Capacitatea : max. 56,0 pF/m (1KHz) | Capacitance : max. 56,0 pF/m (1KHz) | ||||||||
| Impedanta : 100±%15Ω(1MHz) | Impedance : 100±%15Ω(1MHz) | ||||||||
| Frecventa : 155 MHz | Frequency : 155 MHz | ||||||||
| Lungimea de unda: max. : 100m | Length max. : 100m | ||||||||
| Atenuarea : 22 dB (100 MHz) | Attenuation : 22 dB (100 MHz) | ||||||||
| Standard de fabricatie: EIA/TIA 568 | Manufacturing standard: EIA/TIA 568 | ||||||||
| Utilizarea: aceste cabluri asigura o performanta ridicata pina la 155 MHz. | Use: These cables ensure high performans up to 155 MHz. Different and very short | ||||||||
| Pasul de rasucire diferit si foarte scurt aranteaza o atenuare incrucisata | lay lengths of pairs guarantee high crosstalk attenuation values.Screening protects | ||||||||
| ridicata. garanteaza o atenuare incrucisata ridicata.Ecranul protejeaza | vable against electromagnetic interference | ||||||||
| impotriva interferentelor magnetice. | |||||||||
| Culoarea izolatiei perechilor | Core colours | ||||||||
| 1)alb cu albastru/albastru | 1)White-blue stripe / blue | ||||||||
| 2)alb cu portocaliu/portocaliu | 2)White-orange stripe / orange | ||||||||
| 3)alb cu verde/verde | 3)White-green stripe / green | ||||||||
| 4)alb cu maro/maro | 4)White-brown stripe / brown | ||||||||
| Ambalare: colaci de 100 si 200 m acoperiti cu | Standard packing: coils 100 and 200 m covered | ||||||||
| folie din plastic, cutii de carton, bobine. | with plastic foil, in carton boxes, reels | ||||||||
| Simbol cablu Cable symbol | Grosime izolatie Insulation thickness (mm) | Grosime manta Outer sheath thickness (mm) | Diametru exterior Outer diameter (mm) | Greutate Weight (kg/km) | Rezistenta max. Max. conductor resistance (ohm/km) |
||||
| Cat 5e UTP 4x2x0,5 | 0.2 | 0.6 | 5.6 | 60 | 18.1000 | ||||
| Cat 6e UTP 4x2x0,6 | 0.2 | 0.6 | 6.2 | 72 | 18.0000 | ||||
