Description
| TCLIY | |||||||
| Conductoare flexibile de conexiuni pentru telecomunicatii| Telecommunication connection flexible conductors | |||||||
| Constructie | Construction | ||||||
| 1. Conductor flexibil din cupru 2. Izolatie din PVC | 1. Flexible copper conductor, 2. PVC insulation | ||||||
| Specificatia tehnica | Technical specification | ||||||
| Tensiunea nom.: 250 V | Working voltage: 250 V | ||||||
| Tensiunea de incercare: 1000 V | Testing voltage: 1000 V | ||||||
| Temperatura de lucru: min. –30 °C max. +70 °C; | Working temperature: -30°C ¸ +70 °C | ||||||
| Utilizare: canexiuni pentru sisteme de telecomunicatii | Use: for telecommunication connections. | ||||||
| Culoarea izolatiei: conform intelegere | Colour of insulation: acc. with agreement | ||||||
| Standard de fabricatie: SR CEI 60189-3 | Manufactured according to: SR CEI 60189-3 | ||||||
| Ambalare: colaci de 100 – 1000 m | Packing: coils 100 – 1000 m | ||||||
| Nr. conductoare X diametru Core no X diameter (nxmm) | Grosime izolatie Insulation thickness (mm) | Diametru exterior Outer diameter (mm) | Greutate Weight (kg/km) | ||||
| 7X0.2 | 0.6 | 1.8 | 6 | ||||
| 12X0.2 | 0.6 | 2.0 | 8 | ||||
| 16X0.2 | 0.6 | 2.1 | 9 | ||||
| 19X0.2 | 0.6 | 2.2 | 10 | ||||
| 24X0.2 | 0.6 | 2.3 | 12 | ||||
| 32X0.2 | 0.6 | 2.5 | 15 | ||||
| 30X0.25 | 0.6 | 2.8 | 20 | ||||
| ru – conductor rotund unifilar | round solid conductor | |||||||
| rm – conductor rotund multifilar | round stranded conductor | |||||||
| sm –conductor sector multifilar | stranded sector shaped conductor | |||||||
